Zeiss HANDYSURF+ Surface Roughness Tester

Name: Zeiss HANDYSURF+ Surface Roughness Tester
Brand: Aloe Technologies India Private Limited
Price: 125000 INR
Availability: InStock

Price 125000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Zeiss HANDYSURF+ Surface Roughness Tester Specification

Humidity
< 80% RH (Non-condensing)

Power Supply
Rechargeable Li-ion battery / AC Adapter

Number of Specimens
Single measurement per cycle

Resolution
0.001 m (displayed), 0.01 m (measured)

Interface Type
USB 2.0, Bluetooth

Display Type
3.5-inch TFT colour touchscreen

Measuring Range
Up to 100 mRa

Test Range
Ra: 0.01100 m (others per parameter)

Operating Voltage
100-240V AC (with Adapter)

Accuracy
5% of reading

Mounting Type
Handheld

Equipment Type
Surface Roughness Tester

Specimen Size
Not restricted (handheld usage)

Features
Handheld, portable, touch display, fast data output

Automation Grade
Manual

Temperature
0C to 40C (Operating), -10C to 60C (Storage)

Color
grey

Application
Inustrial

Response Time
Immediate measurement display

Usage
Industrial

Machine Weight
About 500 g (including detector and battery)

Test Speed
Approximately 0.6 mm/s

Test Stroke
5.6 mm, optionally 16 mm

Control Mode
Push Button / Touch screen

Battery Life
Up to 800 measurements per charge

Protection Class
IP53 (protected against dust and water spray)

Default Color
grey

Stylus Radius/Angle
2 m / 60

Data Output
USB, Bluetooth (for PC/printer connectivity)

Ra, Rz, Rt, Rq, Rmax and other parameters
Yes, multiple evaluation parameters

Included Accessories
Carrying case, standard roughness specimen, instructions, charger

Detector Type
Standard probe with diamond stylus tip

Memory Capacity
Up to 10,000 measurements stored

Languages
Multilingual operating interface

Zeiss HANDYSURF+ Surface Roughness Tester Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
10 Units Per Month

Delivery Time
10-15 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Zeiss HANDYSURF+ Surface Roughness Tester

Color	grey
Country of Origin	Made in India
location	India
type	new
usage	industrial

Zeiss HANDYSURF+ Surface Roughness Tester is a remarkable surface roughness tester that is equipped with a 2.4-inch color LCD screen, and a user-friendly interface for seamless operations. The device is designed to measure surface parameters during the production processes in the automotive, medical, engineering, and mechanical industries. The tester has several distinguishable features, such as a flexible and robust design that enables horizontal, vertical, and overhead surface measurements. With its intuitive interface, it is user-friendly and quite smooth to operate. The tester complies with ISO, DIN, CNOMO, ASME, and JIS quality standards. It features 20 languages and is compatible with a computer, flash drive, or printer with built-in USB. The roughness testers cover a wide measuring range.

Color	Grey
Country of Origin	Made in India
Location	India
Type	New
Usage	Industrial

"}

Precise Surface Evaluation

The HANDYSURF+ measures a comprehensive range of parameters including Ra, Rz, Rt, Rq, and Rmax, making it suitable for numerous industrial applications. Its diamond stylus tip ensures high accuracy and reliability for all roughness evaluations.

Convenient and Portable Design

With a lightweight build (about 500 g) and included carrying case, the tester is designed for easy handling in both laboratory and field environments. The handheld functionality allows users to assess specimens of unlimited size with maximum flexibility.

Efficient Data Management

Store up to 10,000 measurements and transfer data efficiently through USB or Bluetooth. Immediate measurement display and fast output support streamlined workflows and quick decision-making on the spot.

User-Friendly Operation

Operate the HANDYSURF+ via intuitive touch screen or push buttons. Its multilingual interface and clear display simplify use for various operators, while chargeable lithium-ion battery and AC adapter provide reliable power options.

FAQ's of Zeiss HANDYSURF+ Surface Roughness Tester:

Q: How do I measure surface roughness using the Zeiss HANDYSURF+?

A: To measure surface roughness, power on the device, select your desired parameter (e.g., Ra, Rz), position the diamond stylus on the specimen, and initiate measurement via touch screen or push button. Results display immediately on the colour screen.

Q: What types of parameters can the HANDYSURF+ evaluate?

A: The HANDYSURF+ can assess multiple surface parameters including Ra, Rz, Rt, Rq, Rmax, and others, offering comprehensive analysis suitable for industrial quality control and manufacturing environments.

Q: When should I use the HANDYSURF+ instead of benchtop systems?

A: Choose HANDYSURF+ when portability, rapid setup, and single-handed use are important-especially for large, irregular, or in-situ specimens where traditional benchtop systems are impractical.

Q: Where is the HANDYSURF+ best utilized?

A: HANDYSURF+ is ideally used in industrial settings, manufacturing plants, and quality control labs. Its robust design and IP53 protection allow for reliable performance even in environments exposed to dust and water spray.

Q: What is the process for exporting measurement data from the HANDYSURF+?

A: Measurements can be stored internally and exported easily via USB or Bluetooth to a PC or compatible printer for further analysis, reporting, or record-keeping.

Q: How does the multilingual operating interface benefit users?

A: The multilingual interface allows diverse teams to operate the device comfortably, reducing training time and enhancing usability across different regions and skill levels.

Q: What advantages does the built-in rechargeable battery offer?

A: The lithium-ion battery supports up to 800 measurements per charge, allowing extended operation without frequent recharging, making it highly efficient for field use or multiple shift work.
